| P/N | QDD-400-AOC-xM |
| Cisco Compatible | QDD-400-AOC |
| Form Factor | QSFP-DD to QSFP-DD |
| Max. Data Rate | 400Gbps |
| Cable Length | Customized |
| Cable Type | OM4 |
| Wavelength | 850nm |
| Minimum Bend Radius | 30mm |
| Transmitter Type | VCSEL |
| Receiver Type | 850nm PIN |
| Power Consumption | ≤8W |
| Jacket Material | LSZH |
| CDR (Clock and Data Recovery) | TX & RX Built-in CDR |
| Modulation Format | PAM4 |
| DDM/DOM | Supported |
| Commercial Temperature Range | 0 to 70°C |
| Protocols | IEEE 802.3cd, OIF-CEI-04.0, QSFP-DD MSA, QSFP-DD-CMIS-rev4p0 |
| Inbuilt FEC | No |
| Application | 8x 50G-PAM4 |
| Warranty | 5 Years |
Up to 53.125Gbps Data Rate Per Channel by PAM4 Modulation
Enable 400G Breakout 2x200G Application
Support 400GAUI-8 Electrical Interface
Low Power Consumption <8W Per End
Maximum Link Length: Up to 30m
Hot Pluggable QSFP-DD and QSFP56 Form Factor
Operating Case Temperature Range: 0 to +70°C
EEPROM in Cable Assembly
Pre-FEC Max. BER 2.4E-4
Support RS-FEC
DDM Function Implemented
Single 3.3V Power Supply for Data Center
This active optical cable supports a maximum aggregate data rate of 400Gbps using 8 channels of 50G-PAM4 modulation format.
Yes, it features hot-pluggable QSFP-DD and QSFP56 form factors, allowing you to connect or disconnect the transceiver module without powering down the network equipment.
The cable uses OM4 Multimode Fiber (MMF) operating at an 850nm wavelength, which is ideal for short-reach high-speed interconnects.
It features a low power design with consumption of less than 8W (≤8W) per end, helping to reduce overall energy costs in data centers.
It complies with IEEE 802.3cd, OIF-CEI-04.0, QSFP-DD MSA, and QSFP-DD-CMIS-rev4p0 standards, ensuring high compatibility and reliable performance.
This product is backed by a 5-year warranty, providing long-term reliability and peace of mind for your infrastructure.
