The 25G SFP28 is a Small Form-Factor Pluggable (SFP) transceiver that supports 25 Gigabit per second (Gbps) data rates.
It is a speed-enhanced, backward-compatible version of the SFP+ format, designed for high-speed connectivity in data centers and enterprise networks, and it can connect four SFP28 modules to a QSFP28 transceiver for 100G connections.
Its delivers data rates up to 28Gbps, primarily used for 25G Ethernet connections.
25G SFP28 ports are generally backward-compatible and can accept SFP+ and SFP transceivers, providing flexibility in network upgrades.
For short-range transmissions over multimode fiber.
For long-range transmissions over single-mode fiber.
Directly Attached Copper cables for short distances.
Active Optical Cables with integrated transceivers for high-speed links.
The 25G SFP28 transceiver is designed to support 25 Gigabit per second (Gbps) data rates and can deliver performance up to 28Gbps, primarily optimized for 25G Ethernet connections.
Yes. The SFP28 is a speed-enhanced, backward-compatible version of the SFP+ format. SFP28 ports can generally accept both SFP+ and SFP transceivers, offering high network upgrade flexibility.
Yes, you can achieve 100G connectivity by connecting four SFP28 modules to a single QSFP28 transceiver.
SFP28 SR is designed for short-range transmissions using multimode fiber, while SFP28 LR is designed for long-range transmissions over single-mode fiber.
SFP28 DAC (Directly Attached Copper) features copper cables intended for short distances. SFP28 AOC (Active Optical Cables) utilize optical cables with integrated transceivers to support high-speed links.
The SFP28 BiDi module is compliant with the SFF-8431 standard. Because it is hot-pluggable, it provides significant advantages in terms of reduced system cost, easier upgrades, and enhanced reliability.
